Description

Husqvarna 122HD60

966 53 24-01

 Cutting speed: 4050 cut/min
Knife length: 59 cm
Power output: 0.6 kW
Weight (complete product w/o side packed articles): 4.9 kg

DescriptionThe Husqvarna 122HD60 is a compact and lightweight petrol hedge trimmer for domestic use, with easy to use functions such as Smart Start®, and the benefit of a low noise engine. With an adjustable rear handle this small hedge trimmer with 59cm blade makes easy work of cutting sides and tops of hedges.FeaturesLow Noise EngineThe engine design provides a low noise level and a more pleasant working environment.Smart Start® TechnologySpecially-designed engine and starter for easy and fast starting with minimum effort. Resistance in the starter cord is reduced by up to 40%.LowVib® TechnologyEffective LowVib® dampeners absorb vibration, sparing the user’s arms and hands.Adjustable Rear HandleMultiple handle positions makes hedge cutting easy and comfortableLong cutter barLong cutter bar for extended reachAuto return stop switchStop switch automatically resets to the ON position for trouble-free starting.Quick Start with Air PurgeAir purge removes air from carburetor and fuel system for easy starting.

Capacity

Clutch engagement speed (±120)4300 rpmCutting speed4050 cut/minIdling speed2800 rpmKnife adjustment range, up/down Down0 °Knife adjustment range, up/down Up0 °Max engine/motor9000 rpmMaximum power speed7800 rpmPower output0.6 kWTeeth opening28 mmTorque, max.0.8 NmTorque, max. at rpm6000 rpm

Certifications

Cert machine dir. 2006/42/EC Decl. No.SEC/10/2280

Dimensions

Article gross weight8000 gArticle net weight6030 gKnife length59 cmProduct Size, LxWxH116x23x20 cmRecommended maximum twig diameter20 mmWeight (complete product w/o side packed articles)4.9 kgWeight (excl. cutting equipment)4.9 kg

Engine

CarburetorRuixingCylinder bore32 mmCylinder displacement21.7 cm³Cylinder stroke27 mmElectrode gap0.5 mmEngine Family CARBLHVXS.0224EBEngine Family EPAMHVXS.0224EBGear ratio4.44Ignition module air gap0.3 mmMax engine/motor9000 rpmSpark PlugHusqvarna HQT-4 672201

Equipment

Air filter typeFoamConnectivityNot applicable

Lubricants

Fuel consumption575 g/kWhFuel tank volume0.3 lLubricant type (Engine)Husqvarna 2 stroke or equiv. at 50:1Power/fuel typeGasoline

Packaging

Packaging height282 mmPackaging length1210 mmPackaging volume78.5 dm³Packaging width230 mmQuantity in Master pack1
