Description

HUSQVARNA 522HDR75X

967 65 84-01

Cutting speed:	3200 cut/min
Knife length:	75 cm
Power output:	0.6 kW
Weight (complete product w/o side packed articles):	5.2 kg

DescriptionA 21.7cc, double-sided hedge trimmer with a 75 cm cutter bar and high torque gear for tougher cuts. The multi-position handle and impressively low weight combined with the slim, balanced design and low vibration levels provide excellent handling, while the high capacity, high-speed professional knife blades, open blade guard and impressive power output allows for excellent cutting performance.FeaturesTake on the overgrownThanks to the high-torque gear and the coarse-cut blades, you’ll be able to take on dense or overgrown hedges.Durable, Tested MaterialsInternal gears have been specially designed for long life and tested under tough conditionsQuick Start with Air PurgeAir purge removes air from carburetor and fuel system for easy startingLarge, two-stage air filterThe unloosable two-stage air filter in dual materials and with a large area provide less cost for service and less engine wear.Adjustable Rear HandleMultiple handle positions makes hedge cutting easy and comfortableAuto return stop switchStop switch automatically resets to the ON position for trouble-free starting.Intuitive chokeStarting a cold engine is easier with the intuitive choke which is easy to reach and setLow Noise EngineThe engine design provides a low noise level and a more pleasant working environment.

Capacity

Clutch engagement speed (±120)4400 rpmClutch engagement upper limit6000 rpmCutting speed3200 cut/minIdling speed3000 rpmIdling upper limit4400 rpmMaximum power speed7800 rpmPower output0.6 kWRacing speed lower limit8200 rpmTeeth opening30.5 mmTorque, max.0.9 NmTorque, max. at rpm6000 rpm

Certifications

Cert machine dir. 2006/42/EC Decl. No.SEC/18/2518

Dimensions

Article gross weight7140 gArticle net weight6620 gKnife length75 cmProduct Size, LxWxH127.7×24.6×18.6 cmWeight (complete product w/o side packed articles)5.2 kgWeight (excl. cutting equipment)5.2 kg

Engine

Cylinder bore32 mmCylinder displacement21.7 cm³Cylinder stroke27 mmElectrode gap0.5 mmEngine Family CARBLHVXS.0224ECEngine Family EPAMHVXS.0224ECGear ratio1Ignition module air gap0.3 mmSpark PlugNGK CMR6A

Lubricants

Fuel consumption620 g/kWhFuel tank volume0.45 lPower/fuel typeGasoline

Packaging

Packaging height210 mmPackaging length1320 mmPackaging width260 mmQuantity in Master pack1
